TipoPrint (real case — data altered under NDA) is an industrial print shop in the Aveiro region with 25 employees, specialising in offset printing, large-format digital, packaging and point-of-sale materials. It processes, on average, 180 orders per month from 65 regular clients — from advertising agencies to cosmetics companies and food distributors. When they contacted us, the production director identified the core problem: "We receive orders by phone, email, WhatsApp and even in person. Every order is different, files arrive in the wrong formats, and half the pre-press time is spent requesting information that should have come with the order."
The Diagnosis: Chaos at Intake, Inefficiency in Production
The printing industry is, by nature, complex. Each order has dozens of variables: paper or substrate type, weight, format, number of colours, special finishes (UV varnish, lamination, die-cutting, embossing), print run, fold type, binding and delivery deadline. When these specifications arrive by email or phone in a fragmented manner, errors are inevitable.
At TipoPrint, the audit revealed that 42% of orders required at least one additional contact for specification clarification — wrong file format (RGB instead of CMYK, insufficient resolution, no bleed), incomplete finishing information, or simply dimensions that did not match the intended product. Each clarification contact delayed the order by 1 to 3 days and consumed time from both the sales department and pre-press.
Production planning was managed on a magnetic board on the factory wall. The production manager arranged work orders using coloured post-it notes (urgent, normal, on hold, in production) and redistributed them manually whenever urgencies arose — which happened almost every day. There was no real view of machine capacity, and job sequencing was not optimised — a 4-colour offset run of 5,000 units could be followed by a 2-colour run, when grouping by colour count would significantly reduce setup times.
Material waste was another growing concern. Without systematic tracking, the print shop knew it was wasting paper, ink and plates, but did not know exactly how much, on which orders or for what reasons. The finance director's estimate was "between 8% and 12% of raw material cost", but he acknowledged it was a guess.
Metrics Before the Transformation
• Orders requiring clarification: 42%
• Average clarification time per order: 1–3 days
• Production errors due to incorrect specifications: 6–8 per month
• Estimated raw material waste: 8–12%
• Average setup time between jobs: 45 minutes
• Average delivery time: 8 business days
• Clients with visibility over order status: 0%
The Solution: From Phone to Portal, From Post-it to Digital
1. Online Order Portal with Automatic Validation
We developed a web portal where clients submit orders in a structured way. The portal functions as an intelligent configurator: the client selects the product type (business cards, flyers, catalogues, packaging, etc.), and the system presents only the relevant options for that product — paper, format, finishes, print run.
The most critical component is automatic file validation. When the client uploads the artwork file, the system automatically checks: colour space (CMYK mandatory for offset), minimum resolution (300 DPI), bleed presence (3mm minimum), embedded fonts, file dimensions vs. order dimensions, and ICC profile. If any check fails, the system informs the client immediately, with clear instructions on how to correct it — before the order even reaches pre-press.
Pricing is automatic. Based on the selected specifications and print run, the system presents the price instantly, with volume discounts and an express deadline option (with transparent surcharge). The client can approve and pay online, and the order enters the production system directly — without any human intervention on the sales side.
For clients with recurring orders (for example, a company that reprints the same business cards regularly), the system allows repeating a previous order with one click, updating only the print run if needed.
2. Digital Production Planning
The magnetic board was replaced by a digital planning system that optimises job sequencing. The system knows the capacity of each machine (offset, digital, finishing), setup times per job type and operator availability. When an order enters the system, it is automatically allocated to the most efficient machine and positioned in the production queue in an optimised manner.
Sequencing optimisation was one of the biggest gains. The system groups jobs by number of colours, paper type and format, minimising setup times between consecutive jobs. For example, three 4-colour offset jobs on 170g coated paper are grouped sequentially, even if they have slightly different deadlines — provided all are delivered on time. This optimisation reduced the average setup time from 45 to 22 minutes.
The production dashboard, visible on screens in the factory, shows in real time the status of each machine, the current job, the next job in the queue and deadline alerts. Operators always know the priority, without needing to ask the production manager.
Does your print shop receive orders by email and plan production on a board?
We build bespoke order portals and production planning systems for the printing industry.
See Custom Development →3. Waste Tracking and Actual Costs
We implemented a material tracking system at every stage of production. Operators record on a tablet the actual consumption of paper (sheets used vs. sheets planned), ink and plates. The system automatically compares actual consumption with the theoretical consumption calculated at the quoting stage and identifies deviations.
Each completed order has an actual cost report: raw materials effectively consumed, real machine time and labour. By comparing with the price charged to the client, the print shop knows for the first time the real profitability of each job — not estimated, but measured. They discovered that certain order types (short runs with special finishes) had negative margins, which led to a price adjustment and a more selective acceptance criteria for jobs.
The system generates weekly waste reports by machine, by operator and by job type. The patterns revealed systemic causes: a specific offset machine had paper consumption 15% above expectations (a mechanical problem that was identified and resolved), and a paper type from a particular supplier consistently generated more waste (supplier replaced).
The Implementation: 14 Weeks to a Digital Factory
Weeks 1–3: Order portal. We configured the product catalogue, pricing rules, file validations and approval workflows. We tested with 5 pilot clients representing the most common scenarios.
Weeks 4–7: Production planning. We mapped all machines, setup times, capacities and constraints. We configured the sequencing algorithms and factory dashboards. We integrated with the order portal so new jobs enter the production queue automatically.
Weeks 8–10: Waste tracking. We installed tablets at workstations, trained operators on consumption recording and configured the analysis reports.
Weeks 11–14: Expansion and optimisation. We opened the portal to all clients, adjusted sequencing algorithms with real data and integrated the system with invoicing and accounting software.
The Results: Before vs. After
After five months of operation, results were measured across all dimensions.
• Orders requiring clarification: from 42% to 8% (−81%)
• Production errors due to incorrect specifications: from 6–8/month to 0–1/month
• Raw material waste: from ~10% to 4.2% (−58%)
• Average setup time between jobs: from 45 min to 22 min (−51%)
• Average delivery time: from 8 days to 5 days (−37%)
• Orders processed per month: from 180 to 230 (+28%)
• Sales department time on orders: −65%
• Annual waste savings: ~EUR 32,000
The waste savings alone were transformative. The reduction from ~10% to 4.2% of raw material cost represented an annual saving of approximately EUR 32,000 — money that was literally going in the bin. Tracking also enabled better negotiations with paper suppliers, presenting concrete consumption data and volume projections.
The Portal as a Client Acquisition Tool
An unexpected benefit of the order portal was new client acquisition. TipoPrint made the portal available as a self-service tool: potential clients can configure a product, see the price instantly and place the order — without needing to phone, wait for a quote or negotiate with a sales rep. For clients with simple needs (business cards, flyers, posters), this experience is revolutionary in an industry where the purchasing process is traditionally slow and opaque.
In the first five months, the portal attracted 23 new clients who had never worked with TipoPrint. Most found the portal via online search, demonstrating that the print shop benefited from a digital presence it previously lacked. The acquisition cost for these clients was virtually zero — the portal functions as a permanent salesperson, available 24 hours a day.
Conclusion
The Portuguese printing industry faces intense pressures: margins squeezed by competition from international online platforms, increasing demands for short turnaround times, and environmental sustainability requiring waste reduction. Print shops that continue to receive orders by phone, plan production on magnetic boards and remain unaware of their actual costs are in an increasingly vulnerable position.
TipoPrint demonstrated that digitising a print shop is not just about efficiency — it is about competitive survival. The order portal eliminates sales inefficiencies and opens new acquisition channels. Digital planning maximises machine utilisation and reduces lead times. Waste tracking transforms "guesses" into actionable data. The investment was recovered in under five months, considering waste savings alone — all other benefits are additional return.
